What is high-quality slew bearing?

A bearing is a core component in mechanical engineering. Its core functions can be summarized as: supporting rotating components, reducing friction, and ensuring the efficient and smooth operation of machinery. Simply put, it is a key part that enables machines to “rotate smoothly”.

What is the feature of slew bearing?

Slewing bearing supports have the following characteristics: They can withstand axial forces, radial forces, and overturning moments simultaneously, and can achieve a relatively smooth 360-degree slewing motion. With a compact structure, they occupy a small space, effectively saving the space of the equipment. They are easy to install and can be easily connected and matched with other components. They have a relatively high precision, which can ensure the accuracy and reliability of the slewing motion. They have a large load-bearing capacity, are suitable for various heavy-duty working conditions, and are widely used in fields such as construction machinery and port machinery.

Classification of slew Bearings

There are many ways to classify slew bearings. Here, based on the working principle, we can divide them into:

Rolling bearings: Their main feature is that rolling elements (such as steel balls, rollers) roll between the inner and outer rings to reduce friction.

Advantages: Low friction, high efficiency, and easy maintenance.Disadvantages: Sensitive to foreign objects and require regular lubrication.

Sliding bearings: They have no rolling elements and rely on a lubricating film for direct sliding (such as bearing bushes).

Advantages: Simple structure, impact-resistant, and suitable for high-speed and heavy-load applications.Disadvantages: High friction and require continuous lubrication.

Application of Slew Bearings

Industrial Field

Machine tools: High-precision bearings are used in the spindles of machine tools to ensure the rotational accuracy during tool cutting, guaranteeing the dimensional accuracy and surface quality of the machined parts.

Motors: The rotor of a motor is supported by bearings, enabling the rotor to rotate smoothly, reducing friction losses, and improving the efficiency and service life of the motor.

Metallurgical equipment: For example, the bearings in steel rolling mills need to withstand huge rolling forces to ensure the stable rotation of the rolls and achieve the rolling of steel.

Transportation Field

Automobiles: Wheel hub bearings support the wheels of automobiles, bearing the weight of the vehicle and various forces during driving. At the same time, they ensure the free rotation of the wheels, which is crucial for the vehicle’s handling and safety.

Trains: Axle box bearings are used between the train axles and bogies, adapting to high-speed driving and heavy-load requirements, and ensuring the stability and reliability of train operation.

Aircraft: The bearings in aircraft engines need to operate under high temperature, high speed, and high load conditions, ensuring the stable rotation of the engine rotor, and are key components for the reliable operation of the engine.

Home Appliance Field

Air conditioners: The bearings in air conditioner compressors ensure the rotation of the compressor crankshaft, enabling the compressor to efficiently compress and transport refrigerant.

Washing machines: The rotation of the inner drum of a washing machine relies on bearings for support. They can bear the weight of clothes and water, ensuring the stable operation of the washing machine at different speeds.

Other Fields

Medical devices: High-precision bearings in devices such as CT scanners and MRI machines ensure the precise rotation and positioning of the scanning components, improving the imaging quality.

Robots: The bearings at the joints of robots enable the joints to rotate flexibly, enabling various complex movements, and play a key role in the motion accuracy and stability of robots.

Wind turbines: The main bearings support the impeller shaft of wind turbines, bearing huge axial and radial loads, ensuring the stable rotation of the impeller under different wind speeds and converting wind energy into electrical energy.

How to maintain the bearing

Application Scenarios and Load Requirements

Load Type: Determine the type of load (radial, axial, or combined load) that the bearing will bear, and select the corresponding bearing type (for example, deep groove ball bearings are suitable for radial loads, and tapered roller bearings are suitable for combined loads).

Load Magnitude: Select the bearing size and load-carrying capacity according to the load intensity (refer to dynamic/static load parameters).

Rotational Speed Requirements: For high-speed applications, choose bearings with low friction (such as angular contact ball bearings or ceramic bearings), and ensure that the rated speed limit is not exceeded.

Adaptability to the Working Environment

Temperature:

High-temperature environment: Choose high-temperature-resistant materials (such as stainless steel, ceramic bearings) or adopt cooling measures.

Low-temperature environment: Use low-temperature grease or special alloy bearings.

Corrosion: In humid or chemically corrosive environments, give priority to stainless steel, coated bearings, or sealed bearings.

Dust/Pollution: Select bearings with rubber seals (such as 2RS type) or dust covers (such as ZZ type), or install protective covers externally.

Bearing Types and Structures

Rolling bearings (such as ball bearings, roller bearings):

Advantages: Low friction, high efficiency, and easy maintenance.

Applicable scenarios: Medium to high speed, low impact load (such as motors, machine tools).

Sliding bearings (such as bearing bushes, self-lubricating bearings):

Advantages: Impact-resistant, suitable for heavy-load or low-speed applications.

Applicable scenarios: Metallurgical equipment, large machinery.

Materials and Processes

Material Selection:

Ordinary steel: Economical, suitable for general industrial environments.

Stainless steel: Corrosion-resistant, suitable for the food and chemical industries.

Ceramics (such as silicon nitride): High-temperature-resistant, lightweight, suitable for high-speed or extreme environments.

Manufacturing Process: High-precision bearings (such as P4/P5 grade) are used in precision equipment (such as machine tool spindles, medical instruments).

Lubrication Management

Lubrication Methods:

Grease lubrication: Suitable for medium to low speed, maintenance-free scenarios (such as lithium-based grease).Oil lubrication: Suitable for high speed, high temperature, or heavy load (such as ISO VG 32 – 100 mineral oil).Sealing Design: Sealed bearings (such as rubber-sealed) can reduce contamination and extend the lubrication cycle.

The Price of Bearings

The price of bearings is affected by many factors. For example, different brands use different processes, which will affect the price. Different materials also have different applications, which also affect the price. In addition, market demand is one of the main factors. LDB Company provides many different types and uses of bearings. If you want to know more, you can contact us.

Slew Bearing manufacturer

LDB was established in 1999. It is a company that focuses on scientific and technological innovation, with more than 20 utility model patents, and has won many honorary titles such as Henan Provincial Science and Technology-based Small and Medium-sized Enterprise. We are committed to the design, development, manufacturing, and sales of slewing drives and slewing bearings. If you want to inquire or purchase bearings, you can consult us.
